Product Features：
- Cooling Fan Auto Balancing
- Dual Plane Simultaneous Drilling
- Cycle Time < 15 sec
- 2 Sets of 3-Axis CNC
- Noise < 75 dBA
- CE marking
- Servo Control System
- Auto Deburring
- Industry 4.0 Upgrading
- Fast Troubleshoot by Auto Diagnosis
- Double-station, Double Capacity - Measure and drill at the same time to reduce the cycle time and double the production capacity.
- Data Exchange between Two Station - Auto scheduling reduces the non-efficient time and reaches the prime in production.
- CNC complete the correction in the shortest time by finding the best correction path.
- CNC automatically compute the best drilling position and depth with strict mathematical analysis.
- High precision dual plane vertical balancing machine - Dramatically increase production capacity by getting dual plane unbalance at once.
- Drilling two plane at one station – Increase productivity by reducing transport times.
- High precision unbalance measuring station - Replaceable chuck spindle design makes loading and unloading rotor more convenient and changing model faster.
- AI balancing program - Two stations operate at the same time by using advanced DSP technology to exclude interference from milling station.
- Calibration by standard tool - International traceability and quality guarantee.
- Convenient machine verification - Verify machines at any time with various specifications of standard tools.
- Radar Map - Graphical display make operators read the result easily.
- Support add/remove balancing - Switch the balancing method according to the demand of rotors.
- Servo control system - The precision of CNC can reach 5 um because of the latest technology of servo motor and high-resolution encoder.
- Energy-saving design - Servo control gains higher energy efficiency by improving PWM control.
- Driven through the smart software plays effectiveness of a direct-drive spindle, such as high precision, high stability, high stiffness and high efficiency.
- Direct-drive spindle has higher efficiency than belt-drive spindle and there is no worries about belt maintenance.
- E-tracing - Upload production data to gain high efficiency by big data analysis.
- Barcode – Product management with barcode tracing gets the best quality control.
- Balancing model established - Dramatically improve speed and precision of drilling by the math model before balancing.
- Balancing with components can make sure that and the will be smoother.
- Automatically recycling scrap with high efficiency 1000 L capacity dust collection device makes cleaning and maintenance more conveniently.
- By balancing software automatically controlling the dust collection device, the higher energy efficiency is reached.
- The balancing software conforms with ISO 1940 and determines results as OK/NG automatically according to the standard.
- The built-in ISO 1940 calculator computes the tolerance with rotor properties anytime.
- Easy Operation, Get Started Quickly
- Results Display with Single, Dual and Static Plane
- Flexibly Apply for Adding and Removing Mass Balancing
- Determine OK/NG Automatically
- Graphical Radar Map
- Set Up Tolerance with ISO 1940
- Excel Format Statistics and Report
- Real-time Monitor the Interference from Environment
- Statistics visualize the production information and digitize the management.
- Record and organize measuring data automatically make it as efficient information to benefit the quality control.
